Pulmonary migratory infiltrates (PMI) are observed in a few diseases. We report here a case of PMI attributed to Mycoplasma pneumonia ( Mp) infection. The patient’s past medical history was characterized by fleeting and/or relapses of patchy opacification or infiltrates of parenchyma throughout the whole lung field except for left lower lobe radiographically.
Serological assays revealed an elevation of IgG antibody specific to Mp and its fourfold increase in convalescent serum. Histopathological findings showed polypoid plugs of fibroblastic tissue filling and obliterating small air ways and interstitial infiltrates of mononuclear inflammatory cells in the vicinal alveolar septa. The patient was treated with azithromycin which resulted in a dramatic improvement clinically and imageologically.
In spite of the increasing incidence of Mp, the possible unusual imaging manifestation and underlying mechanism haven’t attracted enough attention. To our knowledge, there are rare reports of such cases. IntroductionPulmonary migratory infiltrates (PMI) are commonly seen in eosinophilic pneumonia (Loeffler’s syndrome), cryptogenic organizing pneumonia, parasitic infestations, Churg-Strauss syndrome, drug reactions etc. Mycoplasma pneumoniae ( Mp), a common cause of community-acquired pneumonia which has nonspecific symptoms such as wheezing, coughing, fever etc., have previously been reported with diverse radiology presentations (,). However, the association of Mp and PMI has been seldom described in literatures before.
Herein, we report a well-documented case of PMI due to Mp infection and review the pertinent literature. Clinical variablesJune 5, 2013–June 26, 2013June 28, 2013–July 13, 2013August 20, 2013–September 2, 2013SymptomsFever (39 °C);nonproductive cough;chest congestionFever; intermittent coughFever (38 °C);fleeting chest pain;discomfort below xiphoidLaboratory data †WBC (4–10 g/L) ‡13.4 (82.7% neutrophils)10.5 (75% neutrophils)7.69CRP (. †, results obtained on admission respectively; ‡, normal values are in parentheses. WBC, white blood cells; CRP, C-reactive protein; NP, not performed; CAT, cold-agglutinin titer.A chest roentgenogram revealed lobar air-space opacities in the right lower lung field at the onset of disease. Cefuroxime was given intravenously as empirical treatment for 6 days which leaded to rare relief clinically and laboratorially.
Before transferred to another hospital, she was evaluated by computed tomography (CT) scan, indicating a new lesion of consolidation in the left upper lobe. The change of antibiotic treatment during her second hospitalization resulted in great improvement as measured by chest roentgenogram other than diffused nodular opacities in the left upper field (not shown). She felt good until the relapse 1 month later and a CT scan on presentation showed patchy opacification with air bronchogram in the right upper lung field and small area of ground-glass opacity in the left upper field. She was also found to have elevated cold-agglutinin titer (CAT) (1:256).
After 12 days’ administration of mezlocillin, the patient still had occasional chest pain and a repeated CT scan revealed recurrence of patchy opacification in the right lower lobe. Chest computed tomography (CT) scan presenting as pulmonary migratory infiltrates (PMI).
Photomicrograph of right lower lobe transbronchial lung biopsy revealing immature polypoid plugs of fibroblastic tissue obliterating respiratory bronchioles and adjacent alveolar ducts (solid arrow). Interstitial infiltrates of mononuclear inflammatory cells within neighbouring alveolar septa are also presented (dashed arrow) (hematoxylin-eosin stain, large image ×200, inset ×400).She continued oral administration of azithromycin for 10 days after discharge from hospital.
Four weeks after hospital discharge, her Mp IgG reactivity in serum was 265 U/mL. On subsequent follow-up over 6 months, the patient had no complaints with periodic chest roentgenographic findings unremarkable. DiscussionPMI was initially recognized from eosinophilic pneumonia (Loeffler’s syndrome). Some other conditions, such as cryptogenic organizing pneumonia, parasitic infestations, Churg-Strauss syndrome, drug reactions etc., can also cause PMI (-).
However, our patient seemed not to be trapped in causes mentioned above due to negative results of eosinophilic in BALF, serum parasitic antibodies or anti-neutrophil cytoplasmic antibodies, recovery without corticosteroid, and a plain medical history. Until now, no literature has described the association of PMI with hysteromyoma. In our case, a long-term Mp reinfection was most likely to be responsible because of the increased CAT (1:256), a positive serum Mp IgG antibody and its fourfold increase in convalescent serum (,).
Besides, azithromycin, which has widely been accepted to be anti-inflammatory and efficient for Mp, leads to both clinical and radiographic improvements.Mp accounts for about 15% to 20% of all community-acquired pneumonia cases and is commonly associated with outbreaks. Although previous reports showed that ground-glass attenuation and air-space opacification which was patchy and segmental or nonsegmental in distribution were common radiological features of Mp infection, a few cases presenting as PMI have been reported (-).
The clinical characteristics of those cases are summarized in. The patients who were confirmed to be infected by Mp through distinct methods could be male or female, and their ages ranged from 11 to 71 years. The onset of symptoms was characterized by fever in all the cases which could be accompanied by cough, muscle ache, sore throat etc. WBC and neutrophils were elevated concomitantly in two patients, as in ours, while WBC and eosinophils were elevated concomitantly in only one patient whose serum IgE was also found to be increased.
All the cases recovered after treated with antibiotics specifically against atypical organisms, corticosteroids, or a combination of both. Our patient responded well to azithromycin, and no additional corticosteroids were administered.
WBC, white blood cells; Mp, Mycoplasma pneumoniae; CF, complement-fixation; NP, not performed; ESR, erythrocyte sedimentation rate; PMI, pulmonary migratory infiltrates.The imaging manifestations of PMI attributed to Mp infection can be diverse. In a case reported by Foy et al., the patient presented as incomplete consolidation in the left lower lobe which turned into infiltrate in the right perihilar region 4 and a half years later. Yang described an 11-year-old boy who developed transient pulmonary masses in the early stage of Mp infection. Of interest, Llibre et al. Reported another case that initially had a segmental infiltrate in the lower right lobe and an alveolar infiltrate in the left upper lobe from chest roentgenogram. And a repeated chest roentgenogram obtained 1 month later revealed bilateral, mainly peripheral, migratory patchy infiltrates. But those infiltrates were distributed within areas that were affected on admission.
Our patient was quite unusual in that the patchy or nodular opacifications and infiltrates of parenchyma were migratory throughout the whole lung field except for left lower lobe in just 3 months, which were recorded by the initial chest roentgenogram and all the later CT scans. To our knowledge, there are no reports of Mp-induced PMI in which such extensive lung fields were involved.Transbronchial lung biopsy of the present patient showed fibroblastic tissue in respiratory bronchioles and adjacent alveolar ducts and interstitial infiltrates of mononuclear inflammatory cells in morbid sites. Those pathological findings, which resembled changes in organizing pneumonia, can be recognized as nonspecific reactions to infectious injury.
It has already been reported that atypical organisms’ infection will lead to organizing pneumonia in some cases who can recover without corticosteroids as ours (,). Our patient presented as both PMI and organizing pneumonia, facts that can be interpreted as follows: The infection of Mp to lower respiratory tract activates macrophages which then begin phagocytosis.
Patchy Opacity And Infiltrates Meaning
Macrophages secrete various cytokines and chemokines attracting more neutrophils and lymphocytes to the site. On one hand, the amplified immune response (including the producing of Mp specific IgA, IgM, IgG, and T-cell-mediated immunity) eliminates organisms in the lesion, but on the other hand, it exacerbates disease through inflammatory damage, such as deterioration of infected cells and excessive proliferation of fibrous tissues. After the elimination of pathogens, the body is able to repair the damaged cells and degrade the newly formed fibrous tissues, process which was thought as histopathologically reversible by Epler et al. In organizing pneumonia patients.
Patchy Opacity And Infiltrates Vs
However, due to the intracellular location and variant in surface antigens, Mp would induce a recurrence or new lesions in the lung.In conclusion, to our knowledge, this is the first well-documented case of Mp infection case presenting as PMI. Several reports can be summed up to a point that PMI with organizing pneumonia should be more defined as a syndrome complex which can been seen in patients with a variety of causes (,). Though rare, Mp infection must be considered in patients with this pattern and poor resolution of empiric anti-infection treatment.
